| 尺寸 |
15.3cm(H)*17.6cm(W)*13.9cm(L) |
配置 |
Optical Input Device (OID), interface, power supply |
| 光學輸入連接器 |
9-pin plastic squeeze-to-release male |
I/O連接器 |
10-pin modular (allows for I/O communications with computer) |
| 通訊介面 |
RS-232, Bluetooth 1.2, (Class 2) (10 meter range), USB 1.1 (2.0 compatible) |
感應器 |
Linear CCD imager, bi-directional scanning |
| 蜂鳴器 |
For audible user feedback of verifi cation results |
LED指示器 |
Red and green LEDs indicate charge state of the internal battery, verifi cation results, and host communication state |
| 檢測光圈 |
3, 5, 6, and 10 mil internal (automatic and manual confi guration options)
3, 5, 6, 10, and 20 mil external reverse video capable |
波長 |
660 nm (internal optics) |
| 工作溫度 |
50° to 104°F (10° to 40°C) |
儲存溫度 |
32° to 104°F (0° to 40°C) |
| 濕度 |
25% to 80% @ 40°C non-condensing |
檢測條碼 |
EAN/UPC with addenda, Code 39 (1-49 characters), Interleaved 2 of 5
(2-78 characters), Codabar, Code 128 (1-70 characters), MSI (1-50 characters), Code 16K (individual rows)
, Code 49 (individual rows), Code 93, Code 11, Regular 2 of 5 (discrete/industrial 2 of 5), IATA 2 of 5
(straight 2 of 5), GS1 DataBar (RSS), Telepen, PDF417, MicroPDF417, and Unrecognized |
|
